Relays
25 results found
FBR51 L (latching)
Automotive relay: Plastic sealed, 30A, 25A at 14VDC contact rating, Dual coil latching, Coil voltage of 10V, 1.11W, PCB TH mount, contact form 1C. Surface mount process capable (Pin-In-Paste)
Share this page
FBR53
Automotive relay: 1 pole, 30 A versions. Coil values from 9V to 12V, plastic sealed. PCB TH mount. From U (form A) contact.
Share this page
FBR53-HC
Automotive relay: 1 pole, 50A versions. Max. inrush current 200A, max. carrying current 67.5A. Coil value 12V. Plastic sealed. TH mount. Reflow capable type available. Form U (formA) contact.
Share this page
FBR53-HW
Automotive relay: 1 pole, 40 A versions. Coil values from 9V to 12V, plastic sealed. PCB TH mount, reflow capable type available. Form U (form A) contact.
Share this page
FBR53-LE
Automotive relay: 1 pole, 40A version. Max. inrush current 200A, max. carrying current 54A. Coil value 12V, plastic sealed. PCB TH mount, contact 1 Form U, reflow capable type available.
Share this page
FBR57
Automotive relay: 1 pole (for 24V battery applications). 1A to 30A contact rating, coil value of 24V, plastic sealed, PCB TH mount, contact form 1C (suitable alternative for form 1A).
Share this page
FBR572 (twin)
Automotive relay: 1 pole x 2 twin type (for 24V battery applications), 1A to 30A contact rating, coil value of 24V, plastic sealed, PCB TH mount, contact form 1Cx2 (suitable alternative for form 1Ax2).
Share this page
FBR582 (twin)
Automotive relay: 1 pole x 2 twin type (for 24V battery applications), 1A to 30A contact rating, coil value of 24V, plastic sealed, PCB TH mount, contact form 1Cx2 (suitable alternative for form 1Ax2).
Share this page
FBR59-HW (12V car battery)
Automotive relay: 1 pole, 70A 14VDC (resistive) or 45A 14VDC (motor) contact rating, coil voltage 9 to 12V, PCB TH mount, contact form 1U, plastic sealed, -40 to +125degC operating temperature range, for 12V car battery, through hole reflow type available.
Share this page
FBR59-HW (24V car battery)
Automotive relay: 1 pole, 30A 28VDC (resistive) contact rating, 70A carrying current, coil voltage 12 and 24V, PCB TH mount, contact form 1U, plastic sealed, -40 to +125degC operating temperature range, for 24V car battery, through hole reflow type available.
Share this page
FTR-B3-AUT
Ultra miniture signal relay for automotive applications, 2 poles, 1A, 30W (30VDC)/0.4W(400VDC), latching or non latching, through hole or surface mount, 1.5 to 24VDC
Share this page
FTR-B4-AUT
Ultra miniture signal relay for automotive applications, 2 poles, 1A, 30W (30VDC)/0.4W(400VDC), latching or non latching, through hole or surface mount, 1.5 to 24VDC
Share this page
FTR-C1-AUT
Ultra miniture signal relay for automotive applications, 2 poles, 1A, 30W (30VDC)/0.4W(400VDC), wide contact gap, latching or non latching, through hole or surface mount, 3 to 24VDC
Share this page
FTR-E1
High voltage DC switching relay: 1 poles, 20A or 30A-450VDC / 20A 800VDC /10A 1000VDC contact rating, coil values 12V and 24V, non polarized contacts, plastic sealed, PCB TH, cULus recognized type available.
Share this page
FTR-E1-HC
High voltage DC switching relay: 1 poles, 60A-450VDC / 10A-1,000VDC, coil values 12V and 24V, non polarized contacts, plastic sealed, PCB TH, cULus/TUV approved.
Share this page
FTR-G1
Automotive relay: 1A to 25A contact rating; coil values of 9, 10 or 12V; plastic sealed case, PCB TH mount, Contact form 1C (form 1A alternative); to 25A switching, reflow capable type available.
Share this page
FTR-G3
Automotive relay: 1 pole, 30A contact ratings, 12V coil value, plastic sealed case, PCB TH mount, contact form 1a or 1c, 30A fuse rate, through hole reflow type available.
Share this page
FTR-K5
Automotive relay: 1 pole, 32A-250VAC, 1a, ambient temperature 105degC, coil voltage 5V to 24V, flux free or plastic sealed
Share this page
FTR-P2 (silent twin)
Automotive relay: 1 pole x 2 twin type, quiet, 25A. Contact ratings from 1A to 25A, coil values of 9V, 10V and 12V, plastic sealed, PCB TH mount, form 1Cx2 (suitable alternative for form 1Ax2).
Share this page
FTR-P3 (12V car battery)
Automotive relay: 1A to 25A contact rating; coil values of 9, 10 or 12V; plastic sealed case, PCB TH mount, Contact form 1C (form 1A alternative); to 25A switching.
